The Lithonia Lighting® EDG Edge-Lit Exit Sign is a single face, red letter exit sign that features top, end or back mounting for installation and a sealed, maintenance free Ni-Cad battery that delivers a minimum of 90 minutes in emergency mode. In addition, the EDG is perfect for applications that need an attractive edge-lit signage.

• DESIGN: Aesthetically pleasing making it perfect for applications that need an attractive edge-lit signage
• ENERGY SAVINGS: Long-life LEDs, coupled with a high-efficiency driver, provide superior illumination for extended service life
• RATINGS & LISTINGS: Certified for damp locations, Title 20, UL924, NFPA 101 (current life safety code), NEC and OSHA illumination standards, All applicable FCC Title 47, Part 15, Subpart B requirements, BAA
• INSTALLATION: Features top, end or back mounting
• HOURS OF LIFE: Long life energy efficient LED
• DESIGN FEATURE BENETFIT: Single face exit sign with red lettering
• BATTERY: EL Option, sealed, maintenance free Ni-Cad battery that delivers a minimum of 90 minutes in emergency mode
• WARRANTY: Buy with confidence with a 5-year limited warranty
• DIMENSIONS: Exit Sign Length length 13-5/8", End Mount: height 11-1/8", Top Mount: height 11-3/4", Back Mount: Height 12-1/8" Canopy Dimensions is 5-1/2" x 4-3/8"
• Lettering measures 6" high, 3/4" stroke, 100ft viewing distance
• Universal chevron indicators for field installation
• For single-face clear panels, exit is seen as a reversed image
• Lithonia Lighting, Life Safety, Emergency Lighting, Edge-Lit Exit, Attractive Exit, Surface Mount Exit, Exit Sign
